Company Advantages
R&D and Production Capability for Full Generation Line Specifications: Our company possesses the ability to develop and produce molybdenum sputtering targets that meet the specifications of all generation lines, ensuring compatibility and optimal performance for various applications.
Sufficient Capacity and Inventory: We maintain abundant production capacity and stock to ensure the uninterrupted supply of molybdenum sputtering targets for your production needs, offering reliability and efficiency.
Advanced Non-Destructive Testing Equipment: With large-scale non-destructive testing equipment capable of an effective range of 4000mm x 2000mm, we ensure that our products are defect-free upon delivery, achieving the perfect coating effect you expect.
Strict and Stable Quality Control: Our rigorous quality control process guarantees that the products we deliver have ultra-high purity of over 99.97%, grain size smaller than 100μm, and a high density of over 10.2g/cm³ (>99%). These qualities are critical to achieving excellent performance in sputtering and coating applications.
Molybdenum sputtering targets are widely used in the thin film coating industry, particularly for applications such as flat panel displays, solar cells, and semiconductor components. Our molybdenum targets offer superior physical and chemical properties, which include:
High Purity: With a molybdenum purity of over 99.97%, our sputtering targets ensure a high-quality film with minimal impurities, contributing to the efficiency and consistency of the coating process.
Fine Grain Size: The grain size of our targets is controlled to be smaller than 100μm, which enhances uniformity during sputtering and improves the quality of the deposited thin film.
High Density: Our molybdenum sputtering targets are manufactured to achieve a density of over 10.2g/cm³, resulting in higher sputtering rates and greater material utilization during the coating process.
Molybdenum Sputtering Target Size: According to customer needs
| Step | Description |
|---|---|
| Raw Material | Selection of high-purity raw materials |
| Reduction | Reduction process to produce molybdenum powder |
| Metal Powder | Production of high-quality molybdenum powder |
| Mixing | Uniform mixing of raw materials |
| Pressing | Pressing into desired shapes |
| Sintering | High-temperature sintering to increase density |
| Forming | Final shaping of molybdenum targets |
| Heat Treatment | Heat treatment to enhance properties |
| Machining/Joining/Coating | Additional processing as needed for application requirements |
| Quality Assurance | Rigorous quality checks to ensure product integrity |
Molybdenum sputtering targets are ideal for a wide range of applications, including:
Flat Panel Displays: Providing excellent electrical conductivity and adhesion properties, our molybdenum targets are suitable for use in TFT-LCD and OLED displays.
Photovoltaic Solar Cells: The high purity and consistent performance of our targets contribute to the efficiency of CIGS and other types of solar cells, enhancing energy conversion rates.
Semiconductor Components: Our molybdenum sputtering targets are used in semiconductor applications that require reliable barrier and adhesion layers.
Our molybdenum sputtering targets are produced with the utmost attention to quality and precision, meeting the demands of high-tech industries. With advanced production capabilities, comprehensive quality control, and a commitment to customer satisfaction, we ensure that our molybdenum targets provide the performance and reliability required for your critical coating applications.
For more information or to request a quote, please contact our sales team. We are here to meet your needs and help you achieve the best possible results in your thin film coating projects.
